(HRE)Seller
ECG Machine
OPTION
ECG 3030p
PRICE / UOM
$450.00 / Each
REMAINING
0
Destination
SHIPPING COST
$0.00
No shipping because weight or quantity has not been provided for this item!
Special Discounts
Product Description
Touch screen Electrocardiogram Machine plus standard accessories
Three channel electrocardiograph
ECG 3030p
Digital 3/6-Channel ECG
Features:
7 inch high resolution color touch-screen
12-lead simultaneous acquisition and display
Auto analysis and diagnosis for routine ECG parameters
Support USB flash disk and micro SD card to extend memory
Software upgrade automatically via USB/SD card.
Specifications:
1. Lead: Standard 12 leads;
2. Input circuit: Floating; Built-in defibrillator protection
3. Acquisition Mode: Simultaneous 12 leads acquisition;
4. Measurement Range: ±5mVpp;
5. Time Constant≥3.2s;
6. Frequency Response: 0.05Hz~150Hz (-3dB);
7. Sensitivity: 2.5mm/mV, 5 mm/mV, 10 mm/mV, 20 mm/mV;
8. Input Impedance ≥50MΩ;
9. Input Circuit Current＜0.05µA;
10. Noise Level ＜15µVp-p;
11. Anti-baseline Drift: Automatic;
12. Patient Current Leakage＜10µA (220V-240V);
13. Filter:
EMG Filter: 25 Hz / 30 Hz / 40Hz/75 Hz / 100 Hz / 150Hz
DFT Filter: 0.05 Hz/ 0.15 Hz
AC Filter: 50 Hz / 60Hz
14. CMRR: 100dB;
15. Recording Mode:
Automatic: 3CH×4+1R, 3CH×4，3CHx2+2CHx3,3CHx2+2CHx3+1R,6CHX2
Manual: 3CH, 2CH, 3CH+1R, 2CH+1R
Rhythm: Any lead selectable
16. Recording way: Thermal printing system;
17. Recording Paper: Roll 80mmx20M;
18. Paper Speed: 12.5 mm/s, 25 mm/s, 50 mm/s;
19. Safety Standard: IEC I/CF;
20. Sample Rate:
Normal: 1000sps/channel
21. Power Supply:
AC: 100~240V, 50/60Hz, 30VA~100VA
DC: 14.8V/2200mAh, built-in lithium battery
Package List:
ECG Machine×1
ECG Lead Wire×1
Limp Clip×4
Chest Suction Ball×6
Thermal Printing Paper×1
Fuse×1
Power Cable×1
